Square Baler

Firma no.
General Features​: Balers are the machines which pick up reaped barrel hay, alfalfa wheat and which tie straw or stalk by pressing with rope. Of the most widespread and useful of baler is the machine which makes the bales whose shape is rectangular prism. Owing to this way, for the public, tansport storage and using will be much easier. The power requied for operation of the machine, is taken by the help of the tractor with shaft. Double – effective hidraulic piston lifting system in the record part helps to pick up all crops from the field by moving up and down. Picking height can be arranged from the drivers side.
Model  SB-55
Length 5440 mm
Width 2520 mm
Height 1740 mm
Weight 1750 kgs
Right Tyre Sizes  10.0/75-15,3PR
Left Tyre Sizes 225/70R15
Working Cpacity 2000/3000 pcs per a day
Bales Sizes  36 X 46 X 135 CM
Tractor Power  45-50 HP
Bale Weight 20/35 KGS
Strock  72 CM
Pick up Width 1535 MM
Knotter Type 2 Twines
